1. Lab Benchtop Wash Material
1. ABS coating. Protects against acid, alkali, salt, etc. Corrosive substances.
2. Material: The main body is 304 stainless steel (new national standard), the wall thickness is 3mm, and it is finely polished.
3. Design pressure: 0.25-0.8MPA, water pressure requirement: 0.25-0.4MPA.
4. Shower: Pull down the lever, the shower water will be ejected from the shower within 1 second, the shower flow is ≧75.7L/min.
5. Eyewash: push the push plate away, the aerosol eyewash is sprayed out within 1 second, and the water height and angle are
Human face proportion design, eyewash flow ≧ 11.4L/min.
6. Eyewash filter: two layers of high-density PP + four layers of 304 stainless steel mesh staggered filter, can filter water
Among the fine impurities, the sprayed water is aerosol-like, embraced and gentle.
7. Ball valve: The two-piece ball valve can make the eyewash water flow accord with American standards.
8. Eyewash assembly: 304 castings are made of finished products, of which 90-degree elbows are made of seamless pipes without welds,
It will not burst the pipe wall due to water pressure during use.
9. Standard base: aluminum alloy + yellow ABS material, high strength, and pressure resistance.
10. Connection of inlet and outlet: DN32 internal thread, middle inlet, and lower drain. It can be customized according to requirements.
11. Performance: It has good resistance to corrosive solutions such as acid, alkali, salt, oil, etc.
