Class II B2 Biological Safety Cabinet

Class II B2 Biological Safety Cabinet

Features:

1. LCD Display control panel helps to monitor all the safety parameters  for better user interface

2. Emission of 253.7 nanometers UV light for most efficient sterilization in cleanroom

3. The transparent side glass windows maximize light and visibility inside the cabinet, providing a bright and open working environment.

Class II B2 Biological Safety Cabinet

1. B2 Biological Safety CabinetMaterial

The B2 biological safety cabinet body is made of cold-rolled steel sheet, processed by laser cutting with error difference less than 0.1 mm,  CNC folding,  full wedding, arc welding, and more than 230-degree high-temperature epoxy coating. Worktop is designed according to the fluid dynamics by stainless steel

2.B2 Biological Safety Cabinet Application

B2 biological safety cabinet offers three protection to lab technicians,, testing samples as well as lab environment. The airflow system is 100% air exhausted out. A  Class II B2 biological safety cabinet is also called a full exhausting hood, which is very necessary when significant amounts of radionuclides and volatile chemicals are expected to be used in the laboratory testing.

3. B2 Biological Safety Cabine Size



Model

BSC-1100IIB2-X

BSC-1300IIB2-X

BSC-1500IIB2-X

BSC-1800IIB2-X

Internal Size

(W*D*H)

940*600*660 mm

1150*600*660 mm

1350*600*660mm

1700*600*660 mm

External Size

(W*D*H)

1100*750*2250mm

1300*750*2250mm

1500*760*2250mm

1873*775*2270mm

Tested Opening

Safety Height 200 mm(8’’)

Max Opening

420mm(17’’)

420mm(17’’)

500mm(20’’)

480mm(20’’)

Inflow Velocity

0.53±0.025 m/s

Down flow Velocity

0.33±0.025 m/s

Pre-Filter

Washable

ULPA Filter

Two, 99.9995% efficiency at 0.12μm,filter life indicator.

Front Window

Motorized,two-layer laminated toughened glass ≥ 5mm,anti UV.

Noise

NSF49 ≤ 61 dB / EN1246949 ≤ 58 dB

UV Lamp

30W*1

30W* 1

40W* 1

40W*1

UV timer, UV life indicator, emission of 253.7 nanometers

for most efficient decontamination.

Illuminating Lamp

LED Lamp

LED Lamp

LED Lamp

LED Lamp

12W*2

14W*2

16W*2

16W*2

Illumination

≥1000Lux

Consumption

700W

850W

900W

1200W

Waterproof Sockets

Two, total load of two sockets: 500W

Display

LCD display: exhaust filter and downflow filter pressure, filter and UV lamp working time,

inflow and downflow velocity, filter life, humidity and temperature, system working time etc.

Control System

Microprocessor

Airflow System

0% air recirculation, 100% air exhaust

Alarm

Abnormal airflow velocity; Filter replacement; Front window at unsafe height.

Exhaust Duct

4 meters PVC duct, Diameter:300mm

Material

Work Zone: 304 stainless steel

Main Body: Cold-rolled steel with anti-bacteria powder coating.

Work Surface Height

750mm

Caster

Foot master caster

Power Supply

AC 220V±10%, 50/60Hz; 110V±10%, 60Hz (110V/60Hz is not applicable to BSC-1800IIB2-X)

Standard Accessory

Illuminating lamp, UV lamp*2,base stand, remote control, foot switch, exhaust blower,

exhaust duct, drain valve, waterproof sockets*2, pipe strap*2

Optional Accessory

Water and gas tap, Electric height adjustable base stand

Gross Weight

246kg

276kg

302kg

408kg

Package

Main Body

1230* 990* 1810 mm

1460*1050*1800 mm

1650*990*1810 mm

2000*950*1820 mm

Exhaust Blower (W*D*H)

970* 810* 630 mm

970* 810* 630 mm

970* 810* 630 mm

970* 810* 680 mm

Chemical Fume Hood Worktop Options
