Project Description

University Lab Bench

PP Lab Universal Extraction Hood For Chemical Gas Exhausting For Island Bench


1. PP material can be resistant to the chemical gas and good option for regular chemical air extraction

2 The flexible arm helps to extract the chemical gas from the equipment on the lab bench

3. The hood is designed according to the hydromechanics to reduce the hood resistance

1. PP Universal Extraction Hood Material

The PP lab universal extraction hood is made of high-density PP (polypropylene) material.  The joint connector is made of  304 stainless steel. Elastic knob is fully made of brass with stainless steel bearing. The fixing base is molded by PP material, instead

2.  PP Universal Extraction Hood Size

Model A   mm B mm C mm D mm E mm Outlet mm
MT-KP11 990 560 720 520 250 110
MT-KP11-1 860 350 550 450 250 110
